How to Disable the Z-Stop in Marlin Firmware

This article explains how to disable the Z-stop functionality in your Marlin firmware. Disabling the Z-stop can be useful for specific applications like automatic bed leveling or certain types of 3D printing projects, but it's crucial to understand the implications before proceeding. Incorrectly configuring this can lead to damage to your printer. Always proceed with caution and understand the risks involved.

Why Disable the Z-Stop?

The Z-stop switch is a safety feature that prevents the print head from crashing into the bed. However, there are situations where temporarily disabling it can be beneficial:

• Auto Bed Leveling (ABL): Some ABL systems require the Z-probe to move beyond the normal Z-stop range to accurately map the bed's surface.
• Specific Print Designs: Certain prints might require a Z-height beyond the Z-stop's limit.
• Troubleshooting: Disabling the Z-stop can aid in troubleshooting Z-axis related issues.

Understanding the Risks

Disabling the Z-stop removes a crucial safety mechanism. Without it, your print head could collide with the bed, causing damage to your printer and potentially injuring yourself. Always exercise extreme caution and monitor your printer closely when the Z-stop is disabled.

How to Disable the Z-Stop in Marlin

The method for disabling the Z-stop varies slightly depending on your Marlin version, but the core principle remains the same: you need to modify the configuration file (Configuration.h). The exact line you need to modify might be slightly different depending on your version, but it will involve the Z_MIN_ENDSTOP_INVERTING and Z_MIN_ENDSTOP_USES_SWITCH configuration options within the Configuration.h file.

Here's a general approach:

1. Locate your Configuration.h file: This file is typically found in your Marlin firmware's directory.

2. Find the relevant lines: Search for lines related to the Z-stop configuration. You'll typically find lines similar to these:

   #define Z_MIN_ENDSTOP_INVERTING false // set to true if the endstop is active low
   #define Z_MIN_ENDSTOP_USES_SWITCH true // set to false to disable the Z-stop


3. Modify the settings: To disable the Z-stop, change the settings as follows:

   #define Z_MIN_ENDSTOP_INVERTING false // Keep this as it is, unless your switch is active low
   #define Z_MIN_ENDSTOP_USES_SWITCH false // Disable the Z-stop switch


   Important Note: The Z_MIN_ENDSTOP_INVERTING setting defines whether your Z-stop switch is normally open (NO) or normally closed (NC). Adjust this setting to match your switch's wiring. If you are unsure, consult your printer's documentation.

4. Compile and Upload: Once you've made the changes, compile the Marlin firmware and upload it to your printer's microcontroller.

5. Test Carefully: After uploading the firmware, carefully test the Z-axis movement. Monitor the printer closely to ensure the print head doesn't collide with the bed.

Alternative Approach (Software Endstop):

Some users prefer using a software endstop, which allows for defining the minimum Z-height through G-code commands. This requires careful calibration and doesn't offer the same level of physical protection as a hardware Z-stop. Refer to your Marlin documentation for details on implementing a software endstop.

Re-enabling the Z-Stop:

To re-enable the Z-stop, simply revert the changes you made in the Configuration.h file to their original values and recompile and upload the firmware.

Remember, disabling the Z-stop introduces significant risk. Use this feature responsibly and understand the potential consequences. Always prioritize safety when working with your 3D printer.
