What Size Breaker for a Mini Split? A Comprehensive Guide

Choosing the right breaker size for your mini split system is crucial for safety and optimal performance. Undersizing can lead to overheating and potential fire hazards, while oversizing is wasteful and unnecessary. This guide will walk you through determining the correct amperage and breaker size for your specific mini split installation. Understanding this is key to ensuring your system runs efficiently and safely for years to come.

Understanding Mini Split Amperage and Breaker Requirements

Mini split systems, also known as ductless air conditioners or heat pumps, draw varying amounts of power depending on their cooling and heating capacity (BTU rating), and the voltage of your system (typically 208V, 230V, or 240V). The amperage draw is specified on the unit's nameplate, usually located on the outdoor unit. This nameplate will list the maximum amperage draw at peak load. This information is paramount in selecting the correct breaker size.

Finding the Information You Need

Before heading to the hardware store, locate the following information on your mini-split system's nameplate:

• Full-Load Amperes (FLA): This is the maximum current the unit will draw during operation. This is the most important number you need.
• Voltage (V): This specifies the voltage required for your system (e.g., 208V, 230V, or 240V).
• Phase (Single or Three-Phase): Most residential mini splits operate on single-phase power.

Calculating Breaker Size

Once you have the FLA, determining the correct breaker size involves following these steps:

1. Consult the NEC (National Electrical Code): The NEC provides guidelines for breaker sizing. While specific rules vary, a common practice is to select a breaker rated at 125% of the FLA. It's always best to consult a qualified electrician to ensure compliance with local codes.

2. Calculation Example: If your mini split’s nameplate lists an FLA of 15 amps, you would calculate: 15 amps * 1.25 = 18.75 amps. Since breakers are typically available in standard sizes, you would round up to the nearest standard size, resulting in a 20-amp breaker in this scenario.

3. Standard Breaker Sizes: Common breaker sizes include 15 amps, 20 amps, 30 amps, and higher. Never use a breaker smaller than the calculated value.

Factors to Consider:

• Future Expansion: If you plan on adding additional mini split units in the future, consider leaving extra capacity in your electrical panel. Consult with a licensed electrician to determine the suitable panel upgrade.

• Other Loads: Account for other loads on the same circuit. Don't overload the circuit by adding other appliances that could cause the breaker to trip frequently.

• Professional Installation: It is highly recommended that the installation of your mini split system, including the electrical wiring and breaker selection, be performed by a licensed and experienced electrician. This ensures safety and compliance with local electrical codes. Incorrect installation could lead to electrical hazards, system malfunctions, and void your warranty.

• Regional Differences: Local building codes may have specific requirements for mini split installations. Always adhere to your area's electrical codes.

Conclusion:

Determining the correct breaker size for your mini split is a critical step in ensuring both safety and optimal performance. While this guide provides a general understanding, consulting with a qualified electrician is highly recommended for a safe and compliant installation. Never attempt electrical work yourself unless you possess the necessary knowledge and experience. The safety of your home and family is paramount.
