Conservative Rankine and Coulomb: Understanding the Differences in Soil Mechanics

This article explores the key differences between the Rankine and Coulomb earth pressure theories, focusing on their conservative nature and applications in geotechnical engineering. Understanding these distinctions is crucial for accurate slope stability analysis and retaining wall design. Both methods are used to estimate active and passive earth pressures, but they differ significantly in their assumptions and resulting predictions.

What are Rankine and Coulomb Earth Pressure Theories?

Both Rankine and Coulomb theories are widely used in soil mechanics to determine the lateral earth pressure exerted by soil on retaining structures. They provide a simplified approach to a complex problem, offering valuable insights for engineers. However, the underlying assumptions differ, leading to variations in their results. The choice between the two depends on the specific soil conditions and the level of accuracy required.

Rankine's Earth Pressure Theory: The Conservative Approach

Rankine's theory is considered more conservative, particularly for active earth pressure calculations. This means it tends to predict higher earth pressures compared to Coulomb's theory. This higher prediction margin enhances the safety factor of the designed structures.

• Key Assumptions: Rankine's theory assumes a perfectly smooth, frictionless wall and a homogeneous soil mass with a constant angle of internal friction. It also assumes the soil behaves as a perfectly plastic material and fails according to Mohr-Coulomb failure criterion. These assumptions simplify calculations, but may not perfectly represent real-world conditions.

• Advantages: Simplicity in calculation, provides a relatively easy-to-understand framework for estimating earth pressures, and its conservative nature makes it safer.

• Disadvantages: It neglects the effect of wall friction, which can significantly influence the actual earth pressures. This simplification can lead to overestimation of active pressure and underestimation of passive pressure, resulting in potentially oversized structures.

Coulomb's Earth Pressure Theory: A More Realistic Approach (But Less Conservative)

Coulomb's theory offers a more realistic representation by incorporating the effect of wall friction. This leads to lower active pressure predictions compared to Rankine's theory. However, this less conservative approach demands more complex calculations.

• Key Assumptions: Coulomb's theory considers the friction between the retaining wall and the soil. It also considers the angle of internal friction of the soil and the angle of wall friction. Like Rankine, it assumes a homogeneous soil mass.

• Advantages: Provides more accurate estimations of earth pressure by considering wall friction, a more realistic model for real-world applications.

• Disadvantages: More complex calculations compared to Rankine's theory, requires more detailed soil parameters (including wall friction angle), and because it accounts for wall friction, it might underestimate the active pressure, potentially leading to less stable designs if not carefully applied.

Conservative Nature and Engineering Considerations:

The "conservatism" of Rankine's theory translates to a higher safety factor. In geotechnical engineering, safety is paramount. While Coulomb's theory may provide more precise estimates, the extra complexity and potentially lower predicted pressure can be problematic. The extra material needed due to Rankine's overestimation is often deemed acceptable compared to the potential risks associated with underestimation.

The choice between Rankine and Coulomb depends heavily on the specific project and engineering judgment. Factors such as soil properties, wall material, and the consequences of failure should be carefully considered. Often, engineers will use both methods as a check on each other's results.

Conclusion:

Both Rankine and Coulomb offer valuable tools for calculating earth pressures. Rankine's approach provides a conservative, simpler solution with inherent safety, while Coulomb's offers a more realistic, but more complex calculation involving wall friction. The ultimate choice depends on the project's specific needs and risk tolerance, balancing simplicity with accuracy. A thorough understanding of both theories is essential for any geotechnical engineer.
